Technical specifications
- Max. sheet size
- 720 x 520 mm
- Min. sheet size
- 220 x 220 mm
- Min. paperweight
- 80 gr/m² (lower on request)
- Max substrate thickness
- 0.6 mm
- Feeder
- Pile
- Stack height
- 600 mm
- Standard die thickness
- 0.8 mm
- Circumferential register
- 360°
- Max. mechanical speed
- Max 10.000 cycles/hour
- Type of cut
- Entire cut and/or kiss cut
- Type of anvil
- Hardened steel and/or magnetic
- Front & side lay
- Offset reference sides respected
Specific advantages
- Unique cylinder configuration with automated impression cylinder change.
- Synchronous and secure auto-insertion of male/female dies.
- Gripper waste used for perfect sheet alignment.
- Standard auto-register over print mark.
- Motor-controlled alignment ruler (storable).
- Minimal registration corrections through sensor monitoring.
- Delayed Sheet Register (DSR system) for automatic correction and waste reduction.
- High energy neodymium magnets for stable die-position.
- Vacuum-controlled transport
- Finger-safe and damage-free die removal.
- Up to 5x longer die-life thanks to perfect cutting length.
- No castors or rails needed – fully accessible single-frame design.
Don’t just take our word for it, watch the machine deliver with your product!
Innovation built on a foundation of trust
Combining decades of mechanical expertise with today’s production demands
Accura FlexCut was developed in close collaboration with Veldkamp BV, a Dutch company with over 40 years of experience in high-precision mechanical engineering. Veldkamp serves clients worldwide with advanced solutions for machinery, control systems, and automation.
By combining this deep technical expertise with modern production insights, Accura Flexcut delivers a die-cutting solution that reduces downtime, minimizes waste, and ensures consistent results, even under today’s demanding production conditions.
Request your free test run
At Accura FlexCut we don’t just talk about innovation, we prove it. With many years of experience in packaging and label finishing, we invite you to our factory to watch the machine create your product in real time. No costs, no obligations, just proof.
